Launch X431 ECU & TCU Programmer Clone BOSCH ME17.8.8

Launch X431 ECU and TCU Programmer Clone BOSCH ME17.8.8

How to clone BOSCH ME17.8.8 with Launch X431 ECU & TCU Programmer on bench? Read the article carefully to learn the procedure. The same operation also applies to X431 X-PROG3 PC Adaptor + GIII.

Launch X431 ECU and TCU Programmer Clone BOSCH ME17.8.8



Open X431 ECU & TCU Programmer software to search:

Make: Baic

Model: Senova 2014-2017

Engine: A151E-1 1500 150

ECU: ME17.8.8 HW2_TC1728



BENCH >> Direct connection of diagram

Connect X431 ECU & TCU Programmer & ME17.8.8 module according to wiring diagram.

Launch X431 ECU and TCU Programmer Clone BOSCH ME17.8.8

Launch X431 ECU and TCU Programmer Clone BOSCH ME17.8.8

Launch X431 ECU and TCU Programmer Clone BOSCH ME17.8.8

Launch X431 ECU and TCU Programmer Clone BOSCH ME17.8.8



Read chip ID.

Read OK, it means the connection is successful.



Read EEPROM data.

Save EEPROM data file.

Read FLASH data.

Save FLASH data file.



Disconnect, then re-connect to a new ECU.

Read chip ID.

Read & save EEPROM data.

Read & save FLASH data.

Write EEPROM data.

Data is successfully written.

Write FLASH data.

Data is successfully written.



BOSCH ME17.8.8 ECU Clone has completed.

Launch X431 ECU and TCU Programmer Clone BOSCH ME17.8.8

Launch X431 ECU and TCU Programmer Clone BOSCH ME17.8.8

Launch X431 ECU and TCU Programmer Clone BOSCH ME17.8.8

Launch X431 ECU and TCU Programmer Clone BOSCH ME17.8.8
